Description
The rod and cylinder of this gas spring are made of AISI 316 stainless steel.
Gas strut 6-15 Stroke 100 – Stainless Steel 316
£157.50
In stock
| Rod diameter | 6mm | 0.24″ |
| Cylinder diameter | 15.6mm | 0.61″ |
| Stroke | 100mm | 3.94″ |
| Length | 248mm | 9.76″ |
| Force | 30 – 450N | 6.7 – 101.2 lbs. |
| Thread | M5 x 0.8 | |
| Progression | 22% | |
| Material | Stainless steel 316 |
Download CAD file
