Ever wondered about the sizing of gas struts, also referred to as gas springs? Effortlessly calculate the ideal gas spring for your application (lid, hatch, etc.) using our user-friendly calculator tool. Navigate and order a gas spring in just 4 uncomplicated steps. We provide an in-depth explanation of these steps on this page, but here’s a quick overview for you. Fancy a visual guide? View our instructional video. Alternatively, download our paper angle meter. Did you realise you can measure the opening and closing angles with your smartphone or tablet? To do so, navigate to gasspringsshop.co.uk/am on your device. Continue reading for a comprehensive breakdown of the gas strut sizing process!
Details of your gas spring application
Our intuitive calculator is a breeze to use. Input the required information and patiently await the result. For a reliable and effective outcome, we require specific details like length, height, angles when closed and open, weight, width, and temperature. Additional data like the number of gas springs intended for use, the pivot point’s location, and the cover material are vital for accurate gas strut sizing.
Understanding gas spring sizing in 4 steps
Whilst a gas spring seems straightforward, several considerations ensure you get the correct size. Our calculator tool is crafted to be as user-friendly as possible, and we constantly enhance it for a seamless experience. It’s ideal for conventional lids or hatches, yet versatile enough for unique applications. Here’s a step-by-step guide:
1. Define the gas spring’s intended purpose.
2. Input the application’s dimensions.
3. Gauge the application’s thickness.
4. Ascertain the application’s material composition.
5. Evaluate the total weight of the application.
6. Pinpoint the pivot point’s location.
7. Decide on the number of gas springs you wish to use.
8. Assess the application’s angle.
Feed the results of these steps into our calculator. It’ll then deduce the most compatible product based on your input.
How does our calculator function?
Upon providing the necessary data, the calculator springs into action. Its real-time simulator offers a glimpse of possible outcomes, such as a hatch opening or closing further. You can preview potential adjustments and rectify them accordingly. Eventually, a 3D illustration and a corresponding force graph will be generated. For instance, the end product might resemble the following:
Remember, you’re free to tweak the gas struts as you see fit. Multiple solutions exist. Any modifications in our calculator instantly reflect in both the simulation and the final calculation.
Order with ease online
Pleased with your gas strut sizing outcome? Ready to make a purchase online? In our calculator’s concluding step, you’ll observe the chosen gas springs, associated mounting parts, and their prices. We advise a thorough review and suggest saving or printing the assembly sketch. Click on the shopping cart icon to proceed. After validating your cart’s contents, finalise your order.
Require additional assistance in selecting or adjusting your gas strut? We’re at your service. Reach out via email at [email protected] or consult our FAQ.
